Pressure Reducing Valve Flanged Inlet / Threaded Inlet
Pressure reducing valve is generally use in high rise buildings which are fully charged with Heavy pressure water supply.
These valves are made in such a way that it’s reduces the outlet pressure range
(4 bar – 8 bar ).
These valves are suitable for use at nominal inlet pressure up to 20 Bar.
Features:-
Body made of Gunmetal.
Hand wheel Made of Cast iron
Blank cap made of Brass with Brass/ Stainless steel chain
Body duly painted in Red color .
Specifications
| Valve Type | Pressure Reducing Flanged Inlet / Threaded |
| Pressure Rating | High Pressure valve |
| Size | 65 mm |
| Body | Brass / Gunmetal |
| Working Pressure | 20 Bar |
| Test Pressure | Seat Test 22 Bar . Body Test 30 Bar |
| Flange | As Per BS Standard |
| Min. Water Flow Rate | 8 L/s @ 4 Bar Outlet Pressure |
| Min. Valve Pressure Regulating | 4 - 8 Bar. |
| Stem | Brass / Gunmetal |
| Bonnet | Brass / Gunmetal |
| Female Inst Outlet | Brass / Gunmetal |
| Washer | Neoprene Rubber |
| Bonnet Seal | Teflon |
| Gland | Brass / Gunmetal |
